Automatic Stainless Steel Aluminum Plate Bending and Flanging Machine Fancy E-Jon ET20C

Ask Lasest Price
Supply Ability :	5000 Set/Sets per Year
Price :	$17,400.00/sets 1-2 sets

Add to Cart

Product Details
Company Profile

Automatic Stainless Steel Aluminum Plate Bending and Flanging Machine Fancy E-Jon ET20C

Product Overview

Introduction

ET20C full-automatic notching and flanging bending machine adds the function ofautomatic notching and cutting for flat metal materia e basis of existing bending machine.The notching and cutting are controlled by servo system, which is high precision, fast spe strong stability. Manipulator alternately feeding structure,the material clamps are castedwhich can avoid scratching the material, meanwhile improving the feeding holding.Using air pressure to press the material,avoid material uneven and ensure the smooth feeding. The double ball screw is matched with nylon gear transmission for precise positioning, which greatly improves the feeding speed and stability of the machine. Plane cutter can slot all kinds of materials. The linear guideway is matched with the ball screw, with 750W high-power servo motor greatly improve the feeding speed and stability.High strength alloy cutters are used for siotting knifes, each knife has 8 angles, no need to sharpen, greatly improve the working life. Double-knife altermate bending structure, the curved knife structure cast by ductile iron,good shock absorption, high structural strength,reduced number of parts splicing,high-power servo motorhigh-speed bending work Under the bending mechanism, the bending mechanism is permanently deformed, which effectively improves the positioning accuracy and the stablity of the high-speed bending.

FEATURES AT A GLANCE

MAINE VIEW

Automatic Stainless Steel Aluminum Plate Bending and Flanging Machine Fancy E-Jon ET20C

Right elevation

Left elevation

Front elevation

PRODUCT SPECIFICATIONS

No	Item	Data
1	Slotting method	Plane cutter
2	Bending method	Double tools alternate bending system
3	Package size	220011801600mm 6606601100mm
4	Working space	326611841783mm
5	Suitable material	Stainless steel,galvanized plate ,aluminum plate
6	Slotting trip	Plane cutter :10-200mm
7	Material thickness	0.4-1.0mm
8	Min. bending angle	R6
9	Min .U	20mm
10	Distanse of internal&external angle	≥10mm
11	Distanse of bending origin	3mm
12	V-cut method	Servo motor control
13	V-cut angle	30°/120°
14	Control system	6 axis control system (4 servo axis control)
15	File formate	Dxf.
16	Power	ax220 、50Hz 、2.0KW
17	Weight	800KG

PRODUCT CONFIGURATION

Deeding

Bending

JV-cut
