Tianjin Ejon Flying Science And Technology Co., Ltd.
2 Years
| Ask Lasest Price | |
| Brand Name : | EJON |
| Certification : | ce |
| Price : | $12,000.00/sets >=5 sets |
SPECIFICATIONS | ||||||
Feeding system | Double ball-screw alternate feeding system | |||||
Slotting System | Plane cutter and alloy milling cutter (double sides cutting) | |||||
Bending System | Double blade alternate bending system | |||||
Suitable Material | Stainless steel, Galvanized steel, Aluminum plate and profile | |||||
Material Height | 20-200mm | |||||
Material Thickness | 0.4~1.2mm | |||||
Accuracy | ±0.1mm | |||||
Min. Bending Angle | R6 | |||||
File Format | Dxf. Plt.Ai | |||||
Power | AC220V、50Hz、2.0Kw | |||||
Weight | 700KG | |||||
Control System | 7 axis control system (3 servo axis control) | |||||
1) Adopts double cutter independent slotting struture, easily deal with various materials.
2) Feeding struture adopts double ball screw with nylon gear transmission, accurate positioning, ensure the feeding smooth, greatly improve the feeding speed and stability of the machine.
3) Configuration of high-power servo motor, effectively improve the positioning accuracy and high-speed bending stability.
The double feeding holder ensures the smooth feeding and avoid
warping.
The monobloc casting of Bending Mechanism has high molding degree
which ensure the bending speed and stability.
Double-cutter slotting, using plane cutter for Galvanized sheet and
Stainless steel,using milling cutter for Aluminum plate and
Aluminum profiles.
Steel coupling ensures the bending molding and bending speed.
To use the device, you need to install the control card in your
computer and then connect to the bending machine and install the
software.Computer configuration : XP system or window7 32-bit system, and requires a PCI card slot to
install the control card.
The use of equipment should be equipped with air compressor, we suggest that the selection of more than 4kw, the gas flow is 0.6m³/Min.
The software of bending machine is self-developed. Import file
format supports .Dxf.Plt .AI We recommend using Coredraw or adobe illustrator to complete the file after the export file to.Dxf.Plt.Ai format. Then open the operating software, select the document.
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
|
|
