| Brand Name : | EJON |
| Price : | $20,000.00/sets >=5 sets |
SPECIFICATIONS | ||||||
Feeding system | Double ball-screw alternate feeding system | |||||
Slotting System | Plane cutter | |||||
Bending System | Double blade alternate bending system | |||||
Suitable Material | Stainless steel, Galvanized steel, Aluminum plate, Aluminium
profile | |||||
Material Height | Stainless steel、Galvanized steel、Aluminum plate:10~200mm | |||||
Material Thickness | 0.4~1.0mm | |||||
Accuracy | ±0.1mm | |||||
Min. Bending Angle | R6 | |||||
File Format | Dxf. | |||||
Power | AC220V、50Hz、2.0Kw | |||||
Control System | 6 axis control system (4 axis servo control) | |||||
1) The bending part adopts structural casting, integral found to ensure the stability of high-speed bending.
2) The feeding structure adopts double ball screw with nylon gear transmission, ensuring smooth feeding and accurate positioning, greatly improving the feeding speed and stability of the machine.
3) The notching and flanging are controlled by servo system, which is high precision, fast speed, strong stability. Equipped with debris storage box, pollution-free, more environmentally friendly.
The casting on Clamping increases the grasping force, meanwhile
does not scratch the material
The double ball screw of feeding design ensure the feeding speed
and precision as well as stability
Double-cutter slotting, using plane cutter for Galvanized sheet and
Stainless steel,using milling cutter for Aluminum plate and
Aluminum profiles.
The encoder module is the key component of the the relation
equipment precision , and the precision casting is used to ensure
the performance of the high precision encoder.
To use the device, you need to install the control card in your
computer and then connect to the bending machine and install the
software.Computer configuration : XP system or window7 32-bit system, and requires a PCI card slot to
install the control card.
The use of equipment should be equipped with air compressor, we suggest that the selection of more than 4kw, the gas flow is 0.6m³/Min.
The software of bending machine is self-developed. Import file
format supports .Dxf.Plt .AI We recommend using Coredraw or adobe illustrator to complete the file after the export file to.Dxf.Plt.Ai format.
Then open the operating software, select the document.
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
|
|
