    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150

    Ask Lasest Price
    Brand Name : Ejon
    Supply Ability : 5000 Set/Sets per Year
    Price : $25,000.00/sets 1-2 sets
    • Product Details
    • Company Profile

    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150

    Product Overview
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Ejon ET80/120/150 Wide Edge Heavy Automatic Bending Machine
    Dobradora de letras metales de tamaño grande
    ET80/ET120/ET150 adopt CNC turning tool as slotting tool, with high strength and low loss. The knife grain has 4 edges on both sides and no need sharpening. Equipped with oil mist lubrication cooling function, prolong the life of knife grains. Adopting progressive clamping feeding design with large feeding torque and high precision, thus effectively avoided material waste and fundamentally saved the cost. The perfect combination of material jig, high quality ball screw, linear guide rail and high power servo drive make it easy to work at high load working state. Cooperating with the material pre-straightening system, the feeding slip phenomenon as well as the deformation of metal sheet is eliminated and avoided in the traditional rolling feeding process.
    Precise mechanical blade systems perform better against thick plates and big wide materials.Software operation is simple, processing graphics without modification of Node, greatly improve the work efficiency.
    Details Images
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    BASE OF THE MACHINE
    * High stability

    * Strong shock resistance

    * Long service without deformation

    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    SLOTTING SYSTEM
    * Low noise

    * No dust pollution

    * Oil mist lubrication cooling
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    BLADES
    * high strength

    * high hardness

    * High wearability


    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    DRIVE SYSTEM
    * High precision

    * High stability

    * Quick response

    * Stable operation
    PRODUCT SPECIFICATIONS
    No
    Item
    Data
    1
    Model
    ET80/ET120/ET150
    2
    Slotting method
    Plane cutter
    3
    Bending method
    Beating
    4
    Package size
    2650*1850*2100mm
    5
    Working space
    6350*1860*2350MM
    6
    Suitable material
    Stainless steel,galvanized steel,aluminum plate
    7
    Slotting trip
    400-850mm/1250mm/1550mm
    8
    Material thickness
    0.4-1.5mm
    9
    Control system
    4 axis control system
    10
    File formate
    Dxf.Plt.Ai
    11
    Power
    AC220V、50Hz、5.0KW
    12
    Weight
    3000KG
    Application
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Company Profile
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Exhibition
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Our Service
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    Automatic Heavy Metal Letter Bending Machine for Super Large Logo Sign Ejon ET80/120/150
    1. We will respond to your demand within 24 hours via email or the platform's official communication tool, and send relevant documents or materials remotely, providing technical support online.
    2. In the case of non-man-made damage to the machine, within the scope of free parts agreed by our both part, we will send free parts within 48 hours (except imported parts or customized parts).
    3. Our engineer can also give training out of China, but the round-tickets and accommodation should be paid by client.
