Product Description
Processing range
Width:≤1300mm
thickness:≤50mm(customizable)is basically not limited
Length:no linited
Power part
Belt drive motor*sets:18.5KW
Platform lifting motor *1set:chuangwei 86BYG250-156
Feed conveying motor "l set:4kw
Brush roller rotation motor *3:4.5kw
Brush roller lifting motor *l set:Chuangwei86BYG250-156
Brush roller revolution motor1 set:VTV200W-100JB20G15 380v
Overall power:47kw
Eccentric cots:Effective 1360mm* diameter 240mm* glue layer20mm
Power of dust removal fan *1:7,5kw(optional)
Operational parameter
Sand Belt speed:≈1100m/min
Feedingspeed:0.5-7.5m/min
Attachment
Abrasive belt size:2200mm*1310mm
Conveyor belt size:6870mm*1300mm
Emery cloth silk wheel "6 groups:320mm*320mm*32mmautomatic
Thickness adjustment mode:Automatic
Others
Pulse dust collector :(filter cartridge *4) (optional)
Thickness adjustment accuracy:<0.05mm
Working air pressure:0.4-0.6Mpa
Peripheraldimension
Size:4100mm*1700mm*2300mm
Weight:4200kg
